Cross-Sectional TEM of Si - NiSi2 Interfaces

Shown are two cross-section of the Si - NiSi2 interface (and the NiSi2 surface).
Facetting of the interface on {111} is very prominent, but the NiSi2 surface shows facets, too..
Faceting inSi Nidisilicide interfaces
